Horizontal shaft shredders
DR4 Shredder
With its 3-beam structure, this sturdy tool is ready for all types of shredding.
For many years now, the DR4 has been unanimously recognised for its versatility : a routine maintenance and crop residue management shredder, suitable for both individual and shared-ownership use. A wide range of options is available for you to configure this shredder to meet your exact requirements.
Key points
Housing
Housing designed around 3 beams for high rigidity and fitted with an easily interchangeable bolt-on armour plate which increases the housing’s resistance to wear.
Rotor
One-piece rotor shaft with double bowl to withstand high mechanical stress.
Large diameter tubes and a wide range of cutting tools for great versatility.
Cutting parts
Reversible Y cutters or pallet cutters (optional) mounted onto treated bushes passing through the 2 supports for extended rotor service life.
Cutting height
Cutting height adjustable with a pair of bolt-on
wear pads and a pair of large-diameter semi-pivoting wheels.
As an option, the basic equipment can be replaced with harder wearing wheels, castor wheels or a roller, to suit all uses.
Cover
Adjustable, rounded rear cover for better distribution of matter on the ground and easy maintenance.
Specifications
| Working width | 2.00 to 3.20 m |
|---|---|
| PTO speed | 540 or 1000 rpm |
| Tractor power | 65 to 200 hp |
| Hitch | category 2 clevis hitch |
| Cutting diameter | 650 mm |
| Number of hammer cutters | 56 to 76 |
| Counter-cutters | removable smooth, top and bottom |
| Terrain tracking | pair of semi-pivoting wheels - pair of bolt-on wear-resistant skids |
| Weight | 1220 to 1730 kg |
| Options | machine can be upgraded to meet your needs. |
