Horizontal shaft shredders

Acco-Road Shredder

Broyeur Acco-road
  • Acco-road-Desvoys
  • Acco Road Desvoys
  • Acco road - Desvoys
Fabriqué en France

Maintain all types of verges and field edges with this particularly robust shredder.

1.60 to 2.20m
70 to 180 hp

The ACCO-ROAD shredder is especially designed for maintaining verges and field edges. Every detail is designed to ensure constant efficiency and remarkable working comfort. Its versatility in terms of coupling and movement means it can adapt to any site.

Request brochures

Key points

Large diameter rotorROTOR acco road

Large diameter rotor fitted with B1 hammer cutters for fine shredding even in difficult, dense vegetation.


DPS safety device: Dual Protect Systemsécurité acco road

Safety in pull modeLogo DPS (dual protect system) : DPS (dual protect system): Safety system in case of impact when moving forwards or reversing with automatic recoil.

System composed of 2 assembled cylinders, coupled to a Nitrogen ball: The first cylinder extends in case of a frontal impact or the second retracts if there is an impact to the rear.

Safety in pushed mode : Increased retraction travel.

BREVETÉ - EN


Tool service lifeAttelage acco-road

Oversize chassis with wear bushes for greater sturdiness and longer life.


Elastic couplingACCOROAD_chassis

Rotor-gearbox connexion with elastic coupling to improve self-alignment in rotation.


Elastic couplingLiaison boîtier-rotor acco-green.JPG

Rotor-gearbox connexion with elastic coupling to improve self-alignment in rotation.

Specifications

Working width 1.60 to 2.20 m
PTO speed 1000 rpm
Tractor power 70 to 180 hp
Hitch category 2 clevis hitch with removable and reversible parallelogram offset
Cutting diameter 435 mm
Number of hammer cutters 20 to 24
Counter-cutters top and bottom
Adjustable terrain tracking reinforced roller and Hardox-ENG-Logotype-CMYK-uai-100skids
Weight 1250 to 1370 kg
Options machine can be upgraded to suit your needs.
