Horizontal shaft shredders
Acco-Road Shredder
Maintain all types of verges and field edges with this particularly robust shredder.
The ACCO-ROAD shredder is especially designed for maintaining verges and field edges. Every detail is designed to ensure constant efficiency and remarkable working comfort. Its versatility in terms of coupling and movement means it can adapt to any site.
Key points
Large diameter rotor
Large diameter rotor fitted with B1 hammer cutters for fine shredding even in difficult, dense vegetation.
DPS safety device: Dual Protect System
Safety in pull mode : : DPS (dual protect system): Safety system in case of impact when moving forwards or reversing with automatic recoil.
System composed of 2 assembled cylinders, coupled to a Nitrogen ball: The first cylinder extends in case of a frontal impact or the second retracts if there is an impact to the rear.
Safety in pushed mode : Increased retraction travel.
Tool service life
Oversize chassis with wear bushes for greater sturdiness and longer life.
Elastic coupling
Rotor-gearbox connexion with elastic coupling to improve self-alignment in rotation.
Elastic coupling
Rotor-gearbox connexion with elastic coupling to improve self-alignment in rotation.
Specifications
Working width | 1.60 to 2.20 m |
---|---|
PTO speed | 1000 rpm |
Tractor power | 70 to 180 hp |
Hitch | category 2 clevis hitch with removable and reversible parallelogram offset |
Cutting diameter | 435 mm |
Number of hammer cutters | 20 to 24 |
Counter-cutters | top and bottom |
Adjustable terrain tracking | reinforced roller and skids |
Weight | 1250 to 1370 kg |
Options | machine can be upgraded to suit your needs. |
